Using a Crate BV120H Blue Voodoo as Donor Amp - APPETITE for DOODOO part 1

354 views· 10 likes· 57:41· Apr 11, 2026

🛍️ Products Mentioned (4)

Today the Tone Priest begins the process of transforming one of the most reviled amps of all time - the Crate BV100H Blue Voodoo (or Blue DooDoo) - into a 100 watt hand wired monster inspired by one of the most mythical amps of all time - the S.I.R. 36 modified Marshall 2203 used by Slash and many other legends. Tony McKenzie S.I.R. 36 & 39 article: https://tonymckenzie.com/afd100_history.htm https://patreon.com/TonePriest https://ko-fi.com/tonepriest https://tone-priest.creator-spring.com/ 0:00 Intro 0:35 The Plan 2:24 Enter the DooDoo 3:16 About the Amps 6:45 Crate BV120H Features 8:47 Blue Voodoo Tone 15:06 Schematic Overview 26:09 Cabinet Construction 27:21 Chassis Construction 29:03 Transformer Wires 30:50 Measuring Inrush Voltage 34:05 Inrush Current Limiter 35:05 Safety Line Capacitors 36:46 Power Transformer Wire Colors 38:50 Output Transformer Wire Colors 40:57 Reverb Tank 42:00 Groove Tubes 44:22 Extracting the PCB 48:34 PCB Analysis & Quality 54:20 Transformer Construction 55:50 End Part 1 - Thank you! = = = = = = = This and all Tone Priest videos are for edu-tainment purposes only. Vacuum tube amplifiers can have lethal voltages in excess of 700 volts. Capacitors can retain a deadly charge even when an amplifier is turned off and unplugged. Videos are not instructional nor do they advocate anyone doing any kind of repairs on their gear. Nobody should do electrical work on anything for any reason ever. Keep your hands and belongings inside the car at all times. tonepriest@gmail.com

About This Video

In this episode I kick off a brand-new questionable life choice: taking one of the most hated amps on the internet—the Crate BV120H “Blue Voodoo” (aka Blue DooDoo)—and using it as a donor to build a 100-watt hand-wired monster inspired by the mythical S.I.R. 36 modded Marshall 2203 that Slash ended up using on Appetite for Destruction. This isn’t going to be a direct clone, but the goal is absolutely in that neighborhood. I talk through why I pivoted from building another Rob Robinette-style SLO clone after my “drilled the chassis wrong” incident, and how I realized the SLO and the SIR 36 live on the same basic topology—different values, same bones. Before I start gutting anything, I actually test the Blue Voodoo as an amp. Clean channel: tons of headroom, but harsh/ice-picky unless you’re brave enough to crank the EQ in weird directions. Dirty channel: usable, loud, and very much “it does the thing it was designed to do,” even if it’s not exactly refined. Then I pull up the schematic and walk through what Crate did here—Fender-ish structure with a couple back-to-back high gain stages stuffed in the middle, optocoupler switching, op-amp loop/reverb, and a 2203-style pre-phase-inverter master volume. Finally, I get into the teardown prep: cabinet/chassis construction, transformer wire color mapping, discovering a bonus 4-ohm OT tap, measuring inrush voltage, identifying the inrush current limiter part, and calling out safety-rated line caps (X/Y). Part 1 is basically reconnaissance: what this amp really is, how it’s built, and what I can reuse before the real surgery begins.
